NEC E Series (32"-65")

LED-Backlit, Commercial-Grade LCD Displays
Ideal for Education, Corporate and Digital Signage Applications

The Essentials

With a brilliant panel and simplified controls, the NEC E Series delivers everything you need for captivating digital signage.

  • Integrated USB Media Player allows for playback of video, audio and picture files.
  • High-definition and high contrast ratio displays provide stunning images.
  • Built-in tuner allows for high-definition broadcast capabilities.
  • Additional energy options include a Power Savings Mode to further reduce energy consumption.
  • 3-year warranty protects your investment.

The Extras

Delivering more than just the basics, the NEC E Series has integrated features that will leave no head unturned.

  • LED backlighting enables eco-friendly digital signage.
  • Simple 24-hour scheduler feature allows for programmable on/off times.
  • Reduced bezel width creates seamless digital signage.
  • Multiple HDMI ports enhance best-in-class connectivity.
  • Internal, 5W - 10W down-firing stereo speakers enhance the experience with superior sound.
  • Ability to wake the display simply by plugging HDMI or VGA into the unit.
Model E327 E326 E436 E506 E656
LCD MODULE Panel Technology VA IPS VA
Viewable Image Size 31.5 31.5" 42.5" 49.5" 64.5"
Native Resolution 1920 x 1080
Brightness (Typical/Minimum) 350 cd/m2 /300 cd/m2
Contrast Ratio (Typical) 4000:1 1400:1 1200:1 3000:1 4000:1
Viewing Angle 178/178 176° Vert., 176° Hor. (88U/88D/88L/88R) @ CR>20
Aspect Ratio 16:9
Displayable Colors Over 16.7 Million
Orientation Landscape
CONNECTIVITY Input Terminals 　
Digital HDMI x3 (1.4) HDMI x3
Analog VGA 15-pin, RCA Composite/Component VGA 15-pin D-SUB, RCA Composite/Component
Audio RCA Audio
External Control LAN, RS232C RS232C (Unidirectional)
Tuner Integrated ATSC (8-VSB, Clear-QAM)/
NTSC Coaxial Tuner		 ATSC (8-VSB, Clear-QAM) / NTSC Coaxial Tuner
USB USB Media Player (5V/500mA) / USB Power Supply (5V/2A) USB Media Player (Video, Audio, Image)
Output Terminals 　
Audio Audio Mini Jack,
RCA Audio		 SPDIF
ADDITIONAL FEATURES Energy Star 7.0, Naviset Administrator 2 Compatible, Wake on Video Signal, ON/Off Schedule Function, Built-In Closed-Captioning (TTS), V-Chip Functionality, USB Media Player, Integrated Speakers, HDR Gamma, IP Addressable, External Control through RS232, Crestron Connected Compatible Built-In ATSC/NTSC Tuner, Wake on Video Signal, On/Off Scheduler Function, Built-In Closed-Captioning (TTS), V-Chip Functionality, USB Media Player, Integrated Speakers (5W x 2 for E326,
10W x 2 for all others)
SHIPS WITH 3.0m AC Power Cable, 2.0m HDMI Cable,
IR Remote Control, Batteries, User Manual		 3m AC Power Cord, 1.8m VGA Cable, Remote Control, Batteries, User Manual
OPTIONAL ACCESSORIES Table Top Stand (ST-32E), All OPS PC's
when coupled with the OPS-DOCK		 Table Top Stand (ST-32E), All OPS PC's when coupled with the
OPS-DOCK		 Table Top Stand (ST-43E), All OPS PC's when coupled with the
OPS-DOCK		 Table Top Stand (ST-50E), All OPS PC's when coupled with the
OPS-DOCK		 Table Top Stand (ST-65E2), All OPS PC's when coupled with the
OPS-DOCK

NEC Large E Series (70"-90")

Commercial-Grade
  • LED backlighting delivers both environmental and economic benefits.
  • Temperature sensors and fans protect the panel from damage.
  • High definition, and contrast ratio deliver superior visual quality.
  • Internal 10W speakers and built-in handles enable a simplified installation.
Connected
  • Comprehensive input panel connects to latest peripherals.
  • Full bi-directional RS-232 control and ethernet control allow individual and groupaddressable control, including email diagnostics.
  • Compatibility with NEC control software PD Comms Tool and NaViSet Administrator 2.
  • Custom input detect feature to prioritize active inputs.
  • Expanded terminal interface including 2 HDMI, DisplayPort, DVI and VGA options.
Adaptable
  • Flexible connectivity with built-in OPS expansion slot for maximum versatility.
  • Extensive control and diagnostic communication provide the highest level of remote management.
  • IR and Button Lock options for protecting against unnecessary setting changes.
Model E705/E705-AVT2 E905/E905-AVT2
LCD MODULE Panel Technology UV2A
A
Viewable Image Size 70" 90"
Native Resolution 1920 x 1080
Brightness (Typical/Minimum) 360/450 cd/m2 280/350 cd/m2
Contrast Ratio (Typical) 4000:1 5000:1
Viewing Angle 176° Vert. / 176 Hor.(88U/88D/88L/88R) @CR>10
Aspect Ratio 16:9
Displayable Colors More than 16.7 million More than 1.07 billion
Orientation 　
CONNECTIVITY Input Terminals 　
  Digital Displayport, HDMI x2, DVI
  Analog VGA 15-pin D-sub
  Audio Audio Mini-Jack x2
  External Control Ethernet (RJ45), RS-232C
  Other USB (Service Port Only)
USB (Service Port Only
Digital Tuner SB-03TM included in OPS slot for -AVT models
USB (Service Port Only
Output Terminals 　
  Audio Audio Mini-Jack, External Speaker Jack x2
Speakers Integrated (10W x 2)
ADDITIONAL FEATURES Integrated Temperature Sensors, Thermodynamic Cooling Fans, Ethernet Control and Communication, RS-232C Control and Communication, AMX Beacon Compatible, Crestron Connected Compatible, Carbon
Footprint Meter, Full 24/7 Scheduler Function, PIP/POP/Side by Side settings, Input Labeling, Built-In Speakers, OPS-Compliant Slot, Custom Input Detect Modes, NaViSet Administrator 2 Compatible, NEC PD
Comms Tool Compatible, IR Lock Settings, Button Lock , Fixed/Variable Audio Out
SHIPS WITH Power Cord, 1.8m DVI-D Cable, Wireless Remote Control, Batteries, CD-ROM, Setup Manual
OPTIONAL ACCESSORIES Single Board Computers All NEC OPS-based Computers
Other SB-03TM (Digital Tuner included in -AVT models), ST-801 (stand), SP-TF1 (thin rear or side-mounted speakers,
15W x 2), SB-01HC (OPS HD-SDI Card), SB-04HC (OPS 3G-SDI Card), ARM based Digital Media Player (OPS-DRD), Large Wall Mount (WMK-6598 ),OPS HDBaseT Receiver (SB-07BC)
